STANDARD mod. SR-H107 - Japan 1962

Standard mod. SR-H107 - Japan 1962  - Portable radio with AM and SW bands, circuit is a superetherodyne with 8 germanium transistor (2SA103, 2SA31, 2SA112, 2SB32, 2SB32, 2SB32, 2SB33, 2SB33) and frequency coverage from 540 to 1606 KHz and 3,9 to 12 MHz, IF frequency is 455 KHz. Power supply: 4 x 1,5V batteries AA type (LR6 or UM3).
Standard mod. SR-H107 - Giappone 1962 - Radio portatile con ricezione in onde medie e corte, il circuito e' una supereterodina con 8 transistor al germanio (2SA103, 2SA31, 2SA112, 2SB32, 2SB32, 2SB32, 2SB33, 2SB33) e copertura in frequenza da 540 a 1600 KHz e da 3,9 a 12 MHz, la media frequenza e' a 455 KHz. Alimentazione: 4 batterie da 1,5 V tipo AA (LR6 or UM3).
