![]() Superheterodyne portable receiver for the Medium Wave band. The circuit uses 9 Tesla germanium NPN transistors: 154NU70, 154NU70, 153NU70, 153NU70, 153NU70, 104NU70, 103NU70, 103NU70, 103NU70. The cabinet is made of pressed cardboard covered in imitation leather and equipped with a carrying handle. Power is supplied by 4 x 1.5 V type C or UM2 batteries. The dimensions are: 8.7 x 5.9 x 3.3 inch (WxHxD) and the weight is 2 lb 10.3 oz. © IK3HIA 2006. |
|||
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
|
![]() Ricevitore portatile supereterodina per la banda delle Onde Medie. Il circuito utilizza 9 transistor NPN al germanio della Tesla: 154NU70, 154NU70, 153NU70, 153NU70, 153NU70, 104NU70, 103NU70, 103NU70, 103NU70. Il mobiletto è in cartone pressato ricoperto di finta pelle e dotato di maniglia per il trasporto. L'alimentazione è fornita da 4 batterie da 1,5 V tipo C o UM2. Le dimensioni sono: 22x15,5x8 cm e il peso è di 1.2 kg. © IK3HIA 2006. |
|||
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
